Lorex LW2003 User Manual

26
12. Technical Specifications
12. TECHNICAL SPECIFICATIONS
Camera
Frequency 2.4 GHz to 2.4835GHz
Maximum Range Extended range up to 450 feet*
*Based on unobstructed line of sight. Actual
range will vary depending on surroundings.
Image Sensor Color CMOS
Lens f 2.5mm, F 2.8
IR LED 9 pcs
Power Adapter: DC 5V, 1000mA
Battery: 3.7V, 1000mA
Video Monitor
Frequency 2.4GHz to 2.4853GHz
Display 2.4" TFT LCD
Display colors 16.7M color LCD
Power Adapter: DC 5V, 1000mA
Battery: 3.7V, 1050mA

Lorex LW2003 Specifications

General Specifications

transmission frequency	ISM 2, 400~2, 482 MHz
transmission power	18 dBm
unobstructed effective range	150 m / 450 ft
spread spectrum	FHSS
modulation mode	GFSK
operating temperature	0-50ºC / 32-122ºF
operating humidity	Less than 90%

Camera Specifications

imaging sensor type	CMOS
picture total pixels	H:240, V:320
minimum illumination	0 Lux (IR on)
night video distance	7 m / 22 ft
view angle	H: 38º V: 50º
image resolution	240 x 320 up to 25 fps
consumption current (max.)	390 mA
power supply	5 V DC
dimensions (W x D x H)	66 x 95 x 115 mm / 2.6 x 3.8 x 4.6"
weight	0.25 kg / 0.5 lbs

Receiver Specifications

LCD screen type	2.4 “ TFT-LCD
effective pixels	H: 240, V:320
receiving sensitivity	<.81 dBm
consumption current (max.)	250 mA
power supply	5 V DC
dimensions (W x D x H)	48 x 17 x 117 mm / 1.9 x 0.7 x 4.6"
weight	0.14 kg / 0.3 lbs

Product Information

package dimensions (LW2003)	199 x 69 x 135 mm / 7.8 x 2.7 x 5.3"
package cube (LW2003)	0.0025 cbm / 0.09 cbf
package weight (LW2003)	0.7 kg / 1.5 lbs
package dimensions (LW2003F)	200 x 69 x 139 mm / 7.9 x 2.7 x 5.5"
package cube (LW2003F)	0.0025 cbm / 0.09 cbf
package weight (LW2003F)	0.7 kg / 1.5 lbs
