Lorex LW2003 User Manual

iii
TABLE OF CONTENTS
1. Video Monitor Overview. . . . . . . . . . . . . . . . . 1
2. Camera Overview . . . . . . . . . . . . . . . . . . . . . . 5
3. Getting Started . . . . . . . . . . . . . . . . . . . . . . . . 6
3.1 Charging the camera . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .6
3.2 Installing the Monitor Battery . . . . . . . . . . . . . . . . . . . . . . . . . . . .7
3.3 Setting Up The Video Monitor . . . . . . . . . . . . . . . . . . . . . . . . . . . .8
4. Pairing Up Cameras . . . . . . . . . . . . . . . . . . . . 9
5. Positioning The Camera . . . . . . . . . . . . . . . 11
6. Using the Baby Monitor . . . . . . . . . . . . . . . . 12
6.1 Selecting the Camera . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .12
6.2 Viewing Options . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .12
6.3 Adjusting Volume . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .14
6.4 Talk function . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .14
6.5 Snapshot function . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .15
6.6 Navigating The Menu . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .16
6.7 Adjusting Screen Brightness . . . . . . . . . . . . . . . . . . . . . . . . . . . .17
6.8 Memory . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .17
6.9 VOX (Audio Activated Alerts) . . . . . . . . . . . . . . . . . . . . . . . . . . . .18
6.10 Power Save (Audio Only Mode) . . . . . . . . . . . . . . . . . . . . . . . . .19
7. Sharing Snapshot Recordings . . . . . . . . . . 20
7.1 Inserting the microSD Card . . . . . . . . . . . . . . . . . . . . . . . . . . . . .21
8. Help . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22
9. Cleaning and Disposal . . . . . . . . . . . . . . . . . 24
11. FCC/IC Notice . . . . . . . . . . . . . . . . . . . . . . . 25
12. Technical Specifications . . . . . . . . . . . . . . 26
13. Wall Mounting Template . . . . . . . . . . . . . . 27

Lorex LW2003 Specifications

General Specifications

transmission frequency	ISM 2, 400~2, 482 MHz
transmission power	18 dBm
unobstructed effective range	150 m / 450 ft
spread spectrum	FHSS
modulation mode	GFSK
operating temperature	0-50ºC / 32-122ºF
operating humidity	Less than 90%

Camera Specifications

imaging sensor type	CMOS
picture total pixels	H:240, V:320
minimum illumination	0 Lux (IR on)
night video distance	7 m / 22 ft
view angle	H: 38º V: 50º
image resolution	240 x 320 up to 25 fps
consumption current (max.)	390 mA
power supply	5 V DC
dimensions (W x D x H)	66 x 95 x 115 mm / 2.6 x 3.8 x 4.6"
weight	0.25 kg / 0.5 lbs

Receiver Specifications

LCD screen type	2.4 “ TFT-LCD
effective pixels	H: 240, V:320
receiving sensitivity	<.81 dBm
consumption current (max.)	250 mA
power supply	5 V DC
dimensions (W x D x H)	48 x 17 x 117 mm / 1.9 x 0.7 x 4.6"
weight	0.14 kg / 0.3 lbs

Product Information

package dimensions (LW2003)	199 x 69 x 135 mm / 7.8 x 2.7 x 5.3"
package cube (LW2003)	0.0025 cbm / 0.09 cbf
package weight (LW2003)	0.7 kg / 1.5 lbs
package dimensions (LW2003F)	200 x 69 x 139 mm / 7.9 x 2.7 x 5.5"
package cube (LW2003F)	0.0025 cbm / 0.09 cbf
package weight (LW2003F)	0.7 kg / 1.5 lbs
