11. FCC/IC Notice
11. FCC/IC NOTICE
This device complies with Part 15, subpart C, of the FCC Rules. Operation
is subject to the following two conditions: (1) this device may not cause
harmful interference, and (2) this device must accept any interference
received, including interference that may cause undesired operation.
The manufacturer is not responsible for any radio or TV interference
caused by unauthorized modifications to this equipment. Such
modifications could void the user’s authority to operate the equipment.
However, it is imperative that the user follows the guidelines in this
manual to avoid improper usage which may result in damage to the unit,
electrical shock and fire hazard injury.
In order to improve the feature functions and quality of this product, the
specifications are subject to change without notice from time to time.

Lorex LW2003 Specifications

General Specifications

transmission frequency	ISM 2, 400~2, 482 MHz
transmission power	18 dBm
unobstructed effective range	150 m / 450 ft
spread spectrum	FHSS
modulation mode	GFSK
operating temperature	0-50ºC / 32-122ºF
operating humidity	Less than 90%

Camera Specifications

imaging sensor type	CMOS
picture total pixels	H:240, V:320
minimum illumination	0 Lux (IR on)
night video distance	7 m / 22 ft
view angle	H: 38º V: 50º
image resolution	240 x 320 up to 25 fps
consumption current (max.)	390 mA
power supply	5 V DC
dimensions (W x D x H)	66 x 95 x 115 mm / 2.6 x 3.8 x 4.6"
weight	0.25 kg / 0.5 lbs

Receiver Specifications

LCD screen type	2.4 “ TFT-LCD
effective pixels	H: 240, V:320
receiving sensitivity	<.81 dBm
consumption current (max.)	250 mA
power supply	5 V DC
dimensions (W x D x H)	48 x 17 x 117 mm / 1.9 x 0.7 x 4.6"
weight	0.14 kg / 0.3 lbs

Product Information

package dimensions (LW2003)	199 x 69 x 135 mm / 7.8 x 2.7 x 5.3"
package cube (LW2003)	0.0025 cbm / 0.09 cbf
package weight (LW2003)	0.7 kg / 1.5 lbs
package dimensions (LW2003F)	200 x 69 x 139 mm / 7.9 x 2.7 x 5.5"
package cube (LW2003F)	0.0025 cbm / 0.09 cbf
package weight (LW2003F)	0.7 kg / 1.5 lbs
