Appendix
Component
Specification
Installation position
Qty.
Steering gear
GB/T9877.1
Rotating shaft lip seal
ring
B30×45×8
Steering vertical arm shaft
1
Lifter
JB/T2600
Framework oil seal
PD42×62×10
Lifting shaft
2
JB/T 982
Sealing gasket
10×13.5
Oil drain plug
1
10×13.5
Cylinder head
2
18×22
Hydraulic output hollow bolt
1
36×42
Refueling vent plug assembly
1
GB/T3452.1
O-ring
71×2.65G
Cylinder liner and housing
sealing
1
17×2.65G
Cylinder head regulating
valve
1
53×5.3G
Piston cylinder barrel
1
53×5.3G
Piston cylinder barrel
1
53×5.3G
Piston cylinder barrel
1
Distributor
GB/T3452.1
O-ring
9×2.65G
Handle shaft, safety valve
seat
1
Joint surface with lifter
housing
1
13.2×2.65G
Safety valve pressure plug
1
15×2.65G
Joint surface with lifter
housing
1
19×2.65G
Joint surface with lifter
housing
1
Oil pump
and oil
circuit
GB/T3452.1
O-ring 18×2.65G
Oil suction point of oil pump
1
