Appendix
11.4 Tractor Chassis Seals:
Table 11-4 List of Tractor Chassis Seals
Component
Specification
Installation position
Qty.
Transmission
case
GB/T 9877.1
Rotating shaft lip seal
ring
B35×55×8
Front end of first shaft
2
FB35×55×8
Inside the bearing cover of
the power output shaft
2
B50×72×8
Outside of drive shaft
6
B55×75×8
Inner side of drive shaft
4
JB/T2600
Framework oil seal
PD50×80×12
Final transmission driving
gear shaft
2
GB/T3452.1
O-ring
11.8×1.8G
Power output fork shaft
1
15×2.65G
Differential lock fork shaft
1
22.4×2.65G
Reverse gear shaft
1
28×3.55G
Final transmission driving
gear shaft
2
67×3.55G
Second shaft front bearing
seat
1
103×3.55G
Rear axle bearing seat
2
112×3.55G
Drive shaft sleeve
2
Brake
GB/T3452.1
O-ring
15×2.65G
Brake camshaft
2
Front axle
Non-standard (see
drawing)
Vertical shaft oil seal
38×74×11.5
Lower end of steering
knuckle
2
Axle shaft oil seal
38×74×11.5
Front wheel hub
2
GB/T3452.1
O-ring
30×3.55G
Upper end of left and right
steering knuckle
2
Both ends of swing shaft
2
105
