Lovol TE Series - Tractor Parking and Engine Shutdown

Operating Instructions
Warning:
1. Ensure that the brake works normally before dispatching the vehicle each time.Otherwise major
accidents such as brake failure will occur;
2.When the tractor is running on the road, be sure to interlock the left and right brake pedals to prevent the
tractor from deviating or even rolling over during braking, causing casualties.
3.10 Tractor parking and engine shutdown
3.10.1 Tractor parking and engine shutdown
 Reduce throttle and tractor running speed.
 Depress the clutch pedal and brake pedal at the same time, and after the tractor stops, put the transmission
shift lever in neutral position.
 Loosen the clutch and brake pedal, and reduce the throttle to idle the engine.
 Pull the transmission shift lever backward to close the tie rod and stop the oil pump from supplying oil. In
this case, the engine will immediately stop. Pull back to the oil supply position.
 Turn the starting switch key to the "OFF" position and turn off all power supplies.
3.10.2 Operation with Machines and Tools
 During the operation with machines and tools attached, the following functions are added to this model for
safety. In the case of the tractor in the neutral position, after the driver leaves the seat, the PTO rocker
switch on the instrument panel is still on. After 5S, the PTO auto power-off mode of the tractor starts, and
the PTO no longer outputs power.
 After the auto power-off mode is turned on, when the driver returns to the seat again, the PTO rocker
switch on the instrument panel shall be disconnected and then turned on again before the PTO can work
again.
Fig. 3-26 Position of PTO Rocker Switch Fig. 3-27 Identification of PTO Rocker Switch
Position of
PTO switch
Identification
of PTO switch
