Function Tab Parameter Description Settings option
Versions, types
SNs, types
Device type Shows which modes are available
Device serial
number
Shows the serial number of the therapy
device.
One-off input of serial number if current
serial number is "0".
Mainboard serial
number
Shows the serial number of the mainboard.
One-off input of serial number if current
serial number is "0".
Blower index Blower version index Currently "0"
Startup logo Shows the activated startup logo.
Versions
Mainboard HW
version
Shows the HW version of the mainboard. Performed automatically
Display HW
version
Shows the HW version of the display. Performed automatically
Display,
touchscreen
Display test
For testing the color rendering of the display
and any pixel errors.
Service for test purposes only; selection
of different color tones.
Recalibrate
touchscreen
Calibration of the touchscreen
Power LED status Check of On/Off button illumination
Start test for
touchscreen
Check of touchscreen reaction
Display brightness
test
Check of display brightness
Beeper control
Check of beeper at 3 different volume
settings
Motor, humidifier
Motor & pressure
control
Flow, l/min Display of current flow
Ambient pressure Display of current ambient pressure
Mask pressure Display of current mask pressure
Device pressure Display of current pressure at device outlet
Motor speed
For checking the flow/pressure depending
on the set blower speed.
For test purposes only; motor speed
Mask pressure
For checking the flow/pressure depending
on a specific pressure.
For test purposes only; setpoint pressure
Humidifier and
hose heater
control
Humidifier current
Humidifier voltage
Shows the current consumption of the
heating element.
For checking the current voltage supply of
the heating element.
For test purposes only; different voltages
Hose heater
connection
Shows whether a heatable hose is
connected.
Hose heater For activating the hose heater.
Voltages
Operating voltage
Shows the current operating voltage of the
therapy device.
Humidifier voltage
Shows the current supply voltage of the
heating element.
External modules
voltage
Shows the current supply voltage of the
system interface.
Motor voltage
Shows the current supply voltage of the
blower.
RTC battery status
Shows whether the internal clock is supplied
with power by the battery.
