60 EN WM 100 TD and WM 100 TH
WM 67971b 09/2017
9 Replacement parts
9 Replacement parts
9.1 Replacement parts list
The item numbers in this chapter are identical to the item numbers in
the chapters "Hygienic preparation" and "Repairs".
Item Designation Article number
Housing
1 Rear of housing, pre-assembled WM 29698
2 Central part of housing, pre-assembled WM 29697
3
Front of housing, pre-assembled up to
SN 4.999
Front of housing, pre-assembled as of SN 5.000
WM 29692
WM 29946
Cables / connections / hoses
4
Connection cable for power supply unit,
complete
WM 29615
5
Connection cable for hose heater
(only applies to devices as of SN 5.000)
WM 29944
6
Holder for connection cable for hose heater
(only applies to devices as of SN 5.000)
WM 29912
7 Decoupling hose WM 29646
8 Ribbon cable for display WM 29634
9 Connection cable for respiratory air humidifier WM 29637
10
Pressure-measurement hose,
comprising:
Angle nozzle
Hose nozzle
Hose, silicone, 4/7 105
Angle nozzle
Hose, silicone, 1.5X0.7 200 B
Hose nozzle
WM 29694
WM 24664
WM 29964
WM 29939
WM 29937
WM 29938
WM 29968
PCBs
11 prisma20A mainboard WM 35015
12 Zubehörteil mainboard WM 35016
13 prismaLAB mainboard WM 35017
14 prisma20C mainboard WM 35018
15 prisma25S mainboard WM 35025
16 prisma25S-C mainboard WM 35026
17 prisma25ST mainboard WM 35027
18 prisma30ST mainboard WM 35028
19 prisma30ST-C mainboard WM 35029
Display
20 Display WM 29633
21 Display frame WM 29635
Screws/nuts/washers
22 Screw EJOT DELTA PT 30X14 WN 5451 WM 50572
23 Screw EJOT DELTA PT 40X25 WN 5452 WM 50563
24 Screw EJOT DELTA PT 40X70 WN 1452 WM 50557
25 Screw EJOT DELTA PT 25X8 WN 5451 WM 50564
Buttons
26 On/Off button, complete, prisma20A WM 29916
27 On/Off button, complete, Zubehörteil WM 29915
