44 EN WM 100 TD and WM 100 TH
WM 67971b 09/2017
7 Repairs
7. Insert device outlet 60 in the therapy device.
8. Insert the cover/respiratory air humidifier.
7.4 Replacing the mainboard
7.4.1 Removing the mainboard
1. Remove the SD card 61 from the SD card slot.
2. Open the therapy device (see "7.2 Opening the therapy device",
page41)
51
52
