Fan
The fan is a centrifugal fan with a precision-balanced fanwheel and a
3-phase motor with Hall effect sensors for continuous speed measure-
ment. The fan is controlled from the mainboard, and the fan speed de-
pends on the current pressure requirements and the current leakage.
1.3.2 WM 100 TH respiratory air humidifier
The heatable respiratory air humidifier functions on the so-called pass-
over principle. The air coming from the therapy device is routed across
the surface of a preheated water reservoir. This increases the relative
humidity and temperature of the air flow.
The humidifier level can be set individually using the buttons on the
therapy device.
The power of the heating element, and consequently the temperature
of the water in the humidifier chamber, is controlled electronically via
the therapy device.
The transparent window of the humidifier chamber makes it possible
to check the water level at any time.
1.4 Warnings in this document
Warnings are used to flag up safety-relevant information.
You will find a warning preceding any action that entails a hazard for
persons or equipment.
Warnings consist of
• the warning symbol (pictogram),
• a signal word designating the hazard level,
• information about the hazard
• instructions for avoiding the hazard.
The warnings appear in three hazard levels, depending on the degree
of danger:
Danger!
Designates an extremely dangerous situation. Failure to
observe this warning will lead to serious, irreversible injury,
or death.
Warning!
Designates an extremely dangerous situation. Failure to
observe this warning may lead to serious, irreversible, or
fatal injury.
Caution!
Designates a dangerous situation. Failure to observe this
warning may lead to minor or moderately serious injury.
Notice!
Indicates a harmful situation. Failure to observe this
warning may lead to damage to equipment.
Designates useful information relating to a particular
action.
