WM 67971b 09/2017
WM 100 TD and WM 100 TH EN 7
2.2 Display
2.2 Display
The information shown on the display depends on the current status
of the therapy device:
• Standby mode (no therapy in progress)
The clock is shown, as is the wake-up time if the alarm clock is set.
• Therapy mode (therapy in progress)
Therapy is in progress (see "2.2.2 Display in patient sector (Start
screen in Therapy mode)", page 8).
• Energy-saving mode
The therapy device is supplied with a very low level of power;
nothing is shown on the display. You can return to Standby mode
by pressing the On/Off button .
2.2.1 Display in patient sector
(Start screen in Standby mode)
2-2 Start screen in Standby mode
No. Designation Description
1 Info menu button Provides access to the info menu.
2 Alarm clock with wake-up time
Alarm clock is set.
Displays the set wake-up time.
3 Menu button Provides access to the settings menus.
4 Dimmer button Dims the display.
5 Clock Displays the current time.
