7 -3
MT563 MT568 MT573
PTO
Type Independent rear PTO
No. of speed 3 speed gears (optional)
PTO / Engine
1st : 540 rpm / 2237 rpm
2nd : 750 rpm / 2471 rpm
3rd : 1000 rpm / 2318 rpm
HYDRAULIC LIFT
3 Point linkage CAT. 2
Draft load detection Upper link sensing type
Lowering speed
control and cylinder
fixing device
Down speed control valve for MHL
Built-in control valve for EHL
Pump Gear type, Engine drive
Rated flow 50.0LPM (13.2GPM)
System pressure 19.0MPa (2756psi)
Lift
capacity
Lower link
end
3000 kg (6614 lb)
24” behind
lift point
2140 kg (4718 lb)
REMOTE
CONTROL
Type Double acting / spring return or detent type (optional)
No. of Q/coupler SAE ½”, 6EA (optional : 4EA)
F/loader coupler Front outlet valve / Joystick loader valve (optional)
STEERING SYSTEM
Type Hydrostatic
Oil Transmission oil
Min. turning radius
(with/without brake)
3427mm (10.8ft) / 3959mm (13.0ft)
Max. steering angle
50°
No. of steering turns 3.6 turns (lock to lock)
Rated oil flow 25.0LPM (6.6GPM)
System pressure 14.5MPa (2103psi)
