3 -53
⑨ Automatic PTO ON/OFF adjustment (EHL)
Notice
▶When adjusting the PTO ON/OFF position, turn the upper-limit setting dial to the
maximum position.
▶ The PTO ON/OFF position saved on controller is available until you set up again.
Position control lever
The position that PTO shaft is stopped can be
adjusted by operator depending on the works.
The adjustment height is restricted within 25%
~75% of the maximum lift stroke. If the set-up is
over the designated range, the set-up is
modified to 25% or 75% automatically.
The manufacturer shall set the position to 50%
when shipping.
When adjusting the position, follow the below
instruction.
1. Align the front wheels straightly ahead according
to the forward direction.
2. Place the rear implement to the suitable position
that is within 25%~75% of the maximum lift
range.
3. If pressing the auto-lift mode switch over 5
seconds, the setup shall be saved with beep
sound.
Upper limit setting dial
Auto-lift mode switch
