101
2) Operation
Operating Method
Selectable among keypad/terminal block/communication
operation
Frequency Setting
Analog: 0 ~ 10[V], -10 ~ 10[V], 0 ~ 20[mA]
Digital: keypad
Operating Function
PID control, up-down operation, 3-wire operation, DC break,
Frequency limit, Frequency jump, Second function, Slip
compensation, Reverse rotation prevention, Auto restarting,
Inverter By-pass, Auto tuning Flying Start, Energy buffering,
Power breaking, Flux breaking, Leakage current reduction,
MMC, Easy Start.
Input
Multi-function
terminal
(8 points)
P1 ~ P8
1)
NPN (Sink) / PNP (Source) selectable
Function:
forward operation, reverse operation, reset, external
trip, emergency stop,
jog operation, sequential frequency-high/medium/low, multi - level
acceleration and deceleration – high/medium/low, D.C. control
during stop, selection of a second motor, frequency increase,
frequency decrease, 3-wire operation, change to general
operation during PID operation, Main inverter body operation
during option operation, analog command frequency fixation,
acceleration and deceleration stop selectable.
Output
Multi-function
open collector
terminal
Failure output and inverter
operation output
Below DC 46V 100mA
Multi-function
relay terminal
Below (N.O., N.C.) AC250V 1A,
Below DC 30V 1A
Analog output
0 ~ 10 Vdc (below 20mA) : selectable from frequency, current,
voltage, direct current voltage
1) The Functions for Multi-function terminal available according to IN-65~72 parameter
setting of IN Group.
