LSIS SV-iS7 series Manual

18
2.4 Motor Connection
Connect motor by following procedure. Check cable specifications on 5.2 before connecting .
1 First, separate the keypad and the cable of keypad(❶)
Ex) 0.75~7.5kW
2 Loosen the bolt that secures the top cover. Then remove the cover by lifting it. (❷)
3 Connect the cables to the power terminals.
❶
❷
