103
(Pollution degree 2 environment)
3) UL Enclosed type 1 with conduit box installed.
5.4 Terminal Screw Specifications
Input/Output Termianl Screw Specification
Inverter applied
Terminal screw
size
Screw torque
1)
(Kgf·cm)
200V
0.75 kW M4 7.1~12
1.5 kW M4 7.1~12
2.2 kW M4 7.1~12
3.7 kW M4 7.1~12
5.5 kW M4 7.1~12
7.5 kW M4 7.1~12
11 kW M6 30.6~38.2
15 kW M6 30.6~38.2
18.5 kW M8 61.2~91.8
22 kW M8 61.2~91.8
30 kW M8 61.2 ~ 91.8
37 kW M8 61.2 ~ 91.8
45 kW M8 61.2 ~ 91.8
55 kW M10 89.7 ~ 122.0
75 kW M10 89.7 ~ 122.0
400V
0.75~1.5kW M4 7.1~12
2.2 kW M4 7.1~12
3.7 kW M4 7.1~12
5.5 kW M4 7.1~12
7.5 kW M4 7.1~12
