22
2.5
AC Input Connection
Connect AC Input power by following procedure. Check cable specifications on 5.2 before
connecting.
1 Connect 3 Phase AC input cable to R,S,T
2 Do not activate the EMC filter if the inverter uses a power source with an
asymmetrical grounding structure, for example a grounded delta connection. Personal
injury or death by electric shock may result.
Ex) 0.75~7.5kW
<Standard type>
To Next Page
