LSIS SV-iS7 series - Page 128

128
Product (kW) Braking Resistor Fuse
37 12 5000 125
500V
45 6 10000 160
55 6 10000 200
75 6 10000 250
90 4.5 15000 350
110 3.5 17000 400
132 3.0 20000 450
160 2.5 25000 450
185 2 30000 620
220 2 30000 800
280 1.5 40000 1000
315 1 60000 1200
375 1 60000 1400
The standard for braking torque is 150% and the working rate (%ED) is 5%. If the working
rate is 10%, the rated capacity for braking resistance must be calculated at twice the
standard.
