46
- You have now shifted to Config Mode.
- Press Mode key once.
- You now route back to Monitor Mode.
2) Mode Shift with User/Macro Mode and Trip Mode
If the user registers the user code or sets the macro function using the multi-function key,
the User/Macro Mode will be displayed unlike the mode shift at the time of the product
delivery. In addition, in case of a trip during operation, the Trip Mode will be displayed and
the trip information will be saved in the trip mode as past history if you withdraw the trip
using RESET function. The mode shift in the two modes is as follows.
- Power on, a display emerges as shown on the
left.
The present mode is the monitor mode.
- Press Mode key once.
- You have shifted to Parameter Mode.
- Press Mode key once.
- You have shifted to User/Macro Mode.
- Press Mode key once.
