Input voltage of 400V class (0.75~22kW)
Type : SV xxx iS7 –
4x
0008
0015
0022
0037
0055
0075
0110
0150
0185
0220
1)
Motor Applied
[HP]
1 2 3 5 7.5 10 15 20 25 30
[kW]
0.75
1.5 2.2 3.7 5.5 7.5 11 15 18.5
22
Rated Output
2)
Rated
Capacity [kVA]
1.9 3.0 4.5
6.1
9.1 12.2
18.3
22.9
29.7
34.3
3)
Rated
Current[A]
CT
2.5 4 6 8 12 16 24
30
39 45
VT
4 6 8 12 16 24
30
39 45
61
Output
Frequency
4)
0 ~ 400 [Hz]
(Sensorless-1: 0~300Hz, Sensorless-2, Vector: 0.1~120Hz)
Output Voltage
[V]
5)
3-phase 380 ~ 480V
Rated Input
Available
Voltage [V]
3-phase 380 ~ 480 VAC (-15%~+10%)
Input Frequency
50 ~ 60 [Hz] (±5%)
Rated
Current [A]
CT
2.2 3.6 5.5 7.5 11.0
14.4
22.0
26.6
35.6
41.6
VT
3.7 5.7 7.7 11.1
14.7
21.9
26.4
35.5
41.1
55.7
* Non DCR products are provided warranty service when used in CT (Heavy duty) load
rating only.
