Input voltage of 400V class (185~375kW)
Type : SV xxx iS7 – 4x 1850 2200 2800 3150 3750 - - - - -
1)
Motor Applied
[HP] 250 300 375 420 500 - - - - -
[kW] 185 220 280 315 375 - - - - -
Rated Output
2)
Rated Capacity [kVA] 286 329 416
467
557 - - - - -
3)
Rated
Current[A]
CT 370 432 547 613 731 - -
-
- -
VT 432 547 613 731 877 - - - - -
Output Frequency
4)
0 ~ 400 [Hz]
(Sensorless-1:0~300Hz, Sensorless-2,Vector:0~120Hz)
Output Voltage [V]
5)
3-phase 380 ~ 480V
Rated Input
Available Voltage [V] 3-phase 380 ~ 480 VAC (-15%, +10%)
Input Frequency
50 ~ 60 [Hz] (±5%)
Rated
Current[A]
CT 404 466 605 674 798 - - - - -
VT 463 590 673 796 948 - - - - -
1) Motor Applied indicates the maximum capacity applied to use of a standard 4 pole
standard motor.
2) Rated capacity : the input capacity of a 200V class is based on 220V and that of a 400V
class is based on 440V. The current rating is based on CT current.
3) The output of rated current is limited according to setting of the carrier frequency (CON-
04).
4) In case of Sensorless-1, you can set the frequency at up to 300Hz by selecting 3, 4 as
the control mode (DRV-09 Control Mode).
In case of Sensorless-2, you can set the frequency at up to 120Hz by selecting 3, 4 as the
control mode (DRV-09 Control Mode).
5) The maximum output voltage does not go up over the supplied power voltage. You can
select the output voltage as you want below the supplied power voltage.
