LSIS XBC-DR14E - Page 234

Parameter
Description Device area per channel
Remark
Value Setting
Ch 0 Ch 1 Ch 2 Ch 3
Ch 4 Ch 5 Ch 6 Ch 7
Comp. output 1
point
designation
HFFFF No use
K321 K351 K381 K411
Word
h0000 P0020
h0001 P0021
h0002 P0022
h0003 P0023
h0004 P0024
h0005 P0025
h0006 P0026
h0007 P0027
h0008 P0028
K2241 K2271 K2301 K2331
h0009 P0029
h000A P002A
h000B P002B
h000C P002C
h000D P002D
h000E P002E
h000F P002F
Unit time [ms]
1 ~ 60,000 ms
K322 K352 K382 K412
Word
K2242 K2272 K2302 K2332
Pulse/Rev.value 1 ~ 60,000
K323 K353 K383 K413
Word
K2243 K2273 K2303 K2333
