Chapter 8 Dedicated Communication
8-18
Variable
Type
Device
Function
Description
_TASK_ER Bit F00044 Task impact
Displayed if identical tasks requested as
duplicated when user program executed.
_BAT_ER Bit F00045 Battery error
Displayed if battery voltage for back-up of
user program and data memory is less than
specified.
_ANNUM_ER Bit F00046
Slight error detected in
external equipment.
Displayed if slight error detected in external
equipment by user program and recorded
on ANC_WB[n].
_LOG_FULL
Bit
F00047
Log memory full warning
Displays PLC’s log memory full.
_HS_WAR1 Bit F00048 HS parameter 1 error
Representative flag used to display HS link
unavailable by checking parameters of HS
link if enabled, which shall be reset if HS
link disenabled.
_HS_WAR2
Bit
F00049
HS parameter 2 error
_HS_WAR3
Bit
F0004A
HS parameter 3 error
_HS_WAR4
Bit
F0004B
HS parameter 4 error
_HS_WAR5
Bit
F0004C
HS parameter 5 error
_HS_WAR6
Bit
F0004D
HS parameter 6 error
_HS_WAR7
Bit
F0004E
HS parameter 7 error
_HS_WAR8
Bit
F0004F
HS parameter 8 error
_HS_WAR9
Bit
F00050
HS parameter 9 error
_HS_WAR10
Bit
F00051
HS parameter 10 error
_HS_WAR11
Bit
F00052
HS parameter 11 error
_HS_WAR12
Bit
F00053
HS parameter 12 error
_P2P_WAR1
Bit
F00054
P2P parameter 1 error
Representative flag used to display P2P
unavailable by checking parameters of
each P2P if enabled, which shall be reset
if P2P disenabled.
_P2P_WAR2
Bit
F00055
P2P parameter 2 error
_P2P_WAR3
Bit
F00056
P2P parameter 3 error
_P2P_WAR4
Bit
F00057
P2P parameter 4 error
_P2P_WAR5
Bit
F00058
P2P parameter 5 error
_P2P_WAR6
Bit
F00059
P2P parameter 6 error
_P2P_WAR7
-
F0005A
P2P parameter 7 error
_P2P_WAR8
-
F0005B
P2P parameter 8 error
_Constant_ER - F0005C Fixed cycle error
It will ON if the scan time is greater than
‘Fixed Cycle’’ specified.
- -
F0005D
~F0005F
- -
