LSIS XGL-EFMT - A.3 List of Flags

Appendix
A-8
A.3 List of Flags
A.3.1 List of Special Relays (F)
Device 1
Device 2
Type
Variable
Function
Description
F0000 - DWORD _SYS_STATE
Mode & Status PLC mode & run status displayed.
-
F00000 BIT _RUN
RUN RUN status.
-
F00001 BIT _STOP
STOP STOP status.
-
F00002 BIT _ERROR
ERROR ERROR status.
-
F00003 BIT _DEBUG
DEBUG DEBUG status.
-
F00004 BIT _LOCAL_CON
Local control Local control mode.
-
F00005 BIT _MODBUS_CON
Modbus mode Modbus control mode.
-
F00006 BIT _REMOTE_CON
Remote mode Remote control mode.
-
F00008 BIT _RUN_EDIT_ST
Modification during
run
Program being downloaded during run.
-
F00009 BIT _RUN_EDIT_CHK
Modification during
run
Modification in progress during run.
-
F0000A BIT _RUN_EDIT_DONE
Modification
complete during run
Modification complete during run.
- F0000B BIT _RUN_EDIT_END
Modification
complete during run
Modification complete during run.
- F0000C BIT _CMOD_KEY
Run Mode Run Mode changed by key.
- F0000D BIT _CMOD_LPADT
Run Mode Run Mode changed by local PADT.
- F0000E BIT _CMOD_RPADT
Run Mode Run Mode changed by remote PADT.
- F0000F BIT _CMOD_RLINK
Run Mode
Run Mode changed by remote
communication module.
- F00010 BIT _FORCE_IN
Compulsory input Compulsory input status.
- F00011 BIT _FORCE_OUT
Compulsory output Compulsory output status.
- F00012 BIT _SKIP_ON
I/O SKIP I/O SKIP being executed.
- F00013 BIT _EMASK_ON
Error mask Error mask being executed.
- F00014 BIT _MON_ON
Monitor Monitor being executed.
- F00015 BIT _USTOP_ON
STOP Stopped by STOP function
- F00016 BIT _ESTOP_ON
ESTOP Stopped by ESTOP function.
- F00017 BIT _CONPILE_MODE
Compiling Compile being performed.
- F00018 BIT _INIT_RUN
Initializing Initialization task being performed.
- F0001C BIT _PB1
Program code 1 Program code 1 selected.
- F0001D BIT _PB2
Program code 2 Program code 2 selected.
