LSIS XGL-EFMT - Page 198

Appendix
A-14
Device 1
Device 2
Type
Variable
Function
Description
F0116
-
WORD _FUSE_ER4 Fuse blown 4 error Added base step 4 Fuse blown error
F0117
-
WORD _FUSE_ER5 Fuse blown 5 error Added base step 5 Fuse blown error
F0118
-
WORD _FUSE_ER6 Fuse blown 6 error Added base step 6 Fuse blown error
F0119
-
WORD _FUSE_ER7 Fuse blown 7 error Added base step 7 Fuse blown error
F0120
-
WORD _IO_RWER0 Module RW 0 error Main base module Read/Write error
F0121
-
WORD _IO_RWER1 Module RW 1 error
Added base step 1 module Read/Write
error
F0122
-
WORD _IO_RWER2 Module RW 2 error
Added base step 2 module Read/Write
error
F0123
-
WORD _IO_RWER3 Module RW 3 error
Added base step 3 module Read/Write
error
F0124
-
WORD _IO_RWER4 Module RW 4 error
Added base step 4 module Read/Write
error
F0125
-
WORD _IO_RWER5 Module RW 5 error
Added base step 5 module Read/Write
error
F0126
-
WORD _IO_RWER6 Module RW 6 error
Added base step 6 module Read/Write
error
F0127
-
WORD _IO_RWER7 Module RW 7 error
Added base step 7 module Read/Write
error
F0128
-
WORD _IO_IFER_0 Module IF 0 error Main base module interface error
F0129
-
WORD _IO_IFER_1 Module IF 1 error Added base step 1 module interface error
F0130
-
WORD _IO_IFER_2 Module IF 2 error Added base step 2 module interface error
F0131
-
WORD _IO_IFER_3 Module IF 3 error Added base step 3 module interface error
F0132
-
WORD _IO_IFER_4 Module IF 4 error Added base step 4 module interface error
F0133
-
WORD _IO_IFER_5 Module IF 5 error Added base step 5 module interface error
F0134
-
WORD _IO_IFER_6 Module IF 6 error Added base step 6 module interface error
F0135
-
WORD _IO_IFER_7 Module IF 7 error Added base step 7 module interface error
F0136 - WORD _RTC_DATE RTC date RTC’s present date
F0137 - WORD _RTC_WEEK RTC day RTC’s present day of the week
F0138 - DWORD
_RTC_TOD RTC time RTC’s present time (ms unit)
F0140 - DWORD
_AC_FAIL_CNT Power-cut times Power-cut times saved.
F0142 - DWORD
_ERR_HIS_CNT Errors found Number of found errors saved.
F0144 - DWORD
_MOD_HIS_CNT
Mode conversion
times
Mode conversion times saved.
F0146 - DWORD
_SYS_HIS_CNT
History updated
times
System’s history updated times saved.
