Installation
Installing the Voice Processing Card
1.
Install the voice-processing card into the upper slot so that the connector of
the card fits securely into the female connector inside the PARTNER MAIL
unit (Figure 2-11).
2.
Install the plastic card spacer so that it holds the upper and lower cards at the
center of the unit, but does not touch any of the components on either card.
3.
Tighten the screw that holds the bracket on the left edge of the unit to secure
the upper card (Figure 2-11)
Tighten Screw
Figure 2-11. Installing a Voice Card
2-16 Add or Replace Voice-Processing Card
