Installation

Remove the #6-32 hex-head screw from the rear panel of the unit.

Insert the PARTNER MAIL unit’s bracket lip into the bracket slot.

Tighten the captive retaining screw into the mounting hole on the unit.

Wall

Slot

Rear panel

Bracket Lip

Captive

Remove screw from

mounting hole

Retaining

Screw

Figure 2-3. Mounting the PARTNER MAIL Unit

2-6 Installing the PARTNER MAIL Unit
