105
User Guide
© 2014 Luxul. All Rights Reserved.
Other trademarks and registered trademarks are the property of their respective owners
CAUTION: Instance Confi g settings will be restored to defaults if the
Switch is restarted and you have not selected Save Confi g
from the main menu and saved your running confi guration to
non-volatile memory.
NOTE: In a Network with both GVRP and MSTP enabled, GVRP packets
are forwarded along the CIST. If you want to broadcast packets of
a specifi c VLAN through GVRP, please be sure to map the VLAN to
the CIST when confi guring the MSTP VLAN-Instance mapping. For
detailed information on GVRP, please refer to the GVRP section of
this guide.
7.3.3 Instance Port Confi g
Ports can play different roles in different Spanning Tree Instances. On this page you can
confi gure the parameters of the Ports in different Instance IDs as well as view status of
the Ports in the specifi ed Instance.
Choose the menu Spanning Tree>>MSTP Instance>>Instance Port Confi g to load the
following page.
Figure 7-9 Instance Port Confi g
