CONFIGURATION PROCEDURE:
Step Operation Description
1
Configure the effective
Time-Range
On ACL>>ACL Time-Range configuration pages,
configure the effective Time-Range for the ACL.
2
Configure ACL Rules On ACL>>ACL Config pages, configure ACL Rules to
Match packets.
3
Configure Policy On ACL>>ACL Policy configuration pages, configure
the Policies used to control the Data packets that
Match the corresponding ACL Rules.
4
Bind the Policy to a Port or
VLAN
On ACL>>ACL Policy Binding configuration pages,
Bind the Policies to a Port or VLAN to bring the Policy
into effect on the corresponding Port or VLAN.
11.5 Application Example for ACL
Network Requirements
The manager of the R&D Department can access to the company Forum and
Internet without any limitations. The MAC Address of the managers computer is
00-46-A5-5D-12-C3.
The staff of the R&D Department cannot access the Internet during work hours but
they are allowed to visit the Forum all day.
The staff of the Marketing Department can access to the Internet all day but cannot
visit the Forum during work hours.
The R&D Department and Marketing Department cannot communicate with
each other.
