282
XMS-1024P
a: 14203 Minuteman Drive, Suite 201, Draper, UT 84020-1685 | luxul.com | 801-822-5450
LUX-UG-XMS-1024P Vers: 081314
Choose the menu Maintenance>>Network Diagnostics>>Trace Route to load the
following page:
Figure 16-10 Trace Route
The following entries are displayed on this screen:
Trace Route Confi g
Destination IP:
Enter the IP Address of the Destination Device.
Max Hop:
Specify the Maximum number of the Route Hops the test Data can
pass through.
17 SAVE CONFIG
The Save Confi g function is used to Save the Running Confi guration of the Switch to
Non-Volatile RAM. If the running confi guration is not saved in this manner, a Reboot or
Power cycle of the switch will cause any custom Confi guration changes to be lost.
Choose the menu Save Confi g to load the following page.
Figure 17-1 Save Confi g
The following is displayed on this screen:
OK: Press the OK button to Save the Running confi guration to Non-Volatile RAM.
Cancel: Press the Cancel button to back out of the Save Confi g option.
