LX160
21.09.06
Page 23
10. Some special functions
10.1. Initialisation of memory
If settings on the LX160 are unusual (e.a. distance is negative), we can set all values back to
the default settings. This action can be done, if we switch off the instrument, push down VOL
and MC together and switch the instrument on. On the LCD we will see a message “data
init”.
Figure 35 Initialisation of memory
10.2. Wiring extension for WinPilot
LX160 with version 2.0 supports communication with WinPilot CE software. For old units with
versions lower than 2.0, a firmware update and wiring upgrade is necessary.
Figure 36 Wiring extension
1
6
2
7
3
8
4
9
5
DB9/F
1
6
2
7
3
8
4
9
5
DB-9/M
1
6
2
7
3
8
4
9
5
DB-9/M
LX160
NMEA
WinPilot
Colibri, LX20, other loggers
and GPS receivers:
Enable only GPGGA,GPRMB
and GPRMC sentences.
WinPilot sentences
should be disabled!
LX160 Ver. 2.XX
Output -> Enabled
(This will enable special
LXWP sentences)
See Ch. 9.13
