Analog Values
Tags
Default value Minimum
range value
Maximum
range value
RT_Cal Room temperature calib Cfg 0.0°F (0.0°C) -3.0°F (-3.0°C) 3.0°F (3.0°C)
Eff_RH Effective humidity used for control Status 40% 0% 100%
HUM_SP Set humidity setpoint Cfg 40% 0% 100%
SAH Supply humidity reading Status 0% 0% 100%
SAH_HL_Set
DEH_SP
Supply humidity high limit setpoint
Set dehum setpoint
Cfg
Cfg
75%
60%
50%
0%
98%
100%
SAT_HL_Set Set supply air high limit setpoint Cfg 104°F (40°C) 0.0°F (0.0°C) 140°F (60°C)
SAT_CTR_Set Set supply air neutral setpoint Cfg 68°F (20°C) 0.0°F (0.0°C) 140°F (60°C)
SAT_LL_Set Set supply air low limit setpoint Cfg 55°F (13°C) 0.0°F (0.0°C) 140°F (60°C)
AV59
AV60
AV65
AV66
AV67
AV68
AV75
AV76
AV77
AV78
AV79
Eff_SAT
ComprLockout
EconoMin_Pos
EconoMaxCO2Pos
OATheatOutAuth
OATeconOutAuth
OAH
OAE
EnthSP
MatSP
MAT
Effective supply air calc. setpoint
Compressor Lockout
Eco min position
Econo max position (for CO2)
Heating authorization (from OAT)
Economizer authorization (from OAT)
Outside air humidity
Outside air enthalpy
Enthalpy setpoint
Mixed air temperature for economizer
Mixed air temperature
Status
Cfg
Cfg
Cfg
Cfg
Cfg
Status
Status
Cfg
Cfg
Status
---
55°F (13°C)
0%
0%
55°F (13°C)
55°F (13°C)
---
---
20 BTU/lbs
65°F (18°C)
---
0.0°F (0.0°C)
0.0°F (0.0°C)
0%
0%
0.0°F (0.0°C)
0.0°F (0.0°C)
0%
10 BTU/lbs
20 BTU/lbs
0.0°F (0.0°C)
0.0°F (0.0°C)
140°F (60°C)
140°F (60°C)
100%
100%
140°F (60°C)
140°F (60°C)
100%
55 BTU/lbs
28 BTU/lbs
140°F (60°C)
140°F (60°C)
Please note that objects tagged as:
• Cfg: represent configuration properties of the device that are typically only set once during commissioning and start-up
• User: represent properties or objects that are typically manipulated by users of the controller
• Status: represent objects or properties that are ‘’typically’’ meant to be displayed on graphics for various required visualization
• Cmd: represent objects that can be controlled directly by other BACnet external process
