Multi-State Values
Please note that objects tagged as:
• Cfg: represent configuration properties of the device that are typically only set once during commissioning and start-up
• User: represent properties or objects that are typically manipulated by users of the controller
• Status: represent objects or properties that are ‘’typically’’ meant to be displayed on graphics for various required visualization
• Cmd: represent objects that can be controlled directly by other BACnet external process
www.lynxspring.com
Object
Instance
RTU
Object name
Tags
Default value State texts
MSV1
CFGSens
Description
Remote thermistor 10K Cfg Type 3 Type 3
Type 2
MSV2
AI_RS Select room temperature input Cfg Intern Intern
AI-1
AI_2
AI-3
AI-4
MSV3
MODE System mode User On Off
Auto
Cool
Heat
MSV4
FAN Set fan mode User Auto On
Auto
MSV5
Eff_Occ Effective occupancy mode Status --- Occupied
Unoccup
TempOcc
Standby
MSV6
Loc-Occ Occupancy command User Loc-Occ Loc_Occ
Occupied
Unoccup
