Lynxspring onyxx LX BW437-RTU-LX - MSV7-MSV10 Configuration

Object
Instance
RTU
Object name
Description
Tags
Default value State texts
MSV7
CFG_Y1 Set cooling output 1 operation Cfg None None
Off-On
0-10V D(direct)
0-10V R(reversed)
2-10V D(direct)
2-10V R(reversed)
Pulsed D(direct)
Pulsed R(reversed)
MSV8
CFG_Y2 Set cooling output 2 operation Cfg None ‘’Same as above’’
MSV9
CFG_Y3 Set cooling output 3 operation Cfg None None
Off-On
MSV10
CFG_Y4 Set cooling output 4 operation Cfg None None
Off-On
Please note that objects tagged as:
• Cfg: represent configuration properties of the device that are typically only set once during commissioning and start-up
• User: represent properties or objects that are typically manipulated by users of the controller
• Status: represent objects or properties that are ‘’typically’’ meant to be displayed on graphics for various required visualization
• Cmd: represent objects that can be controlled directly by other BACnet external process
Multi-State Values
Please note: MSV, 7, 8, 9, 10, 16, 17, 18, 19, 23, 27, 28, 30, 32, 44, 45, 46, 48, 49 52, 54, 55, 65 & 68 are used for ‘’custom’’ configuration applications.
Make sure MSV127 is set to ‘’custom’’ BEFORE setting any of those MSV’s
