Default value State texts
CFG_W1 Set heating output 1 operation Cfg None None
Off-On
0-10V D(direct)
0-10V R(reversed)
2-10V D(direct)
2-10V R(reversed)
Pulsed D(direct)
Pulsed R(reversed)
O (O/B)
B (O/B)
CFG_W2 Set heating output 2 operation Cfg None ‘’Same as above’’
CFG_W3 Set heating output 3 operation Cfg None None
Off-On
CFG_W4 Set heating output 4 operation Cfg None None
Off-On
Please note that objects tagged as:
• Cfg: represent configuration properties of the device that are typically only set once during commissioning and start-up
• User: represent properties or objects that are typically manipulated by users of the controller
• Status: represent objects or properties that are ‘’typically’’ meant to be displayed on graphics for various required visualization
• Cmd: represent objects that can be controlled directly by other BACnet external process
Multi-State Values
