Default value State texts
CFG_FAN Select fan output Cfg BO1 BO1
BO2
AO1
AO2
BO1_AO1
BO1_AO2
AI_OAT Select outside air temp. input Cfg None None
AI-1
AI-2
AI-3
AI-4
External
AI_SAT Select supply air temp. input Cfg None ‘’Same as above’’
AO_ECO Select economizer output Cfg None None
BO-5
BO-6
BO-7
AO-1
AO-2
AO-3
AO-4
Please note that objects tagged as:
• Cfg: represent configuration properties of the device that are typically only set once during commissioning and start-up
• User: represent properties or objects that are typically manipulated by users of the controller
• Status: represent objects or properties that are ‘’typically’’ meant to be displayed on graphics for various required visualization
• Cmd: represent objects that can be controlled directly by other BACnet external process
Multi-State Values
