Lynxspring onyxx LX BW437-RTU-LX - Analog Values

Analog Values
Object
Instance
RTU
Object name
Description
Tags
Default value Minimum
range value
Maximum
range value
AV1
RoomTSP Room Temperature setpoint User 72°F (22°C) 54°F (12°C) 90°F (32°C)
AV6
HTG_Dem Heating demand Status --- 0% 100%
AV7
CLG_Dem Cooling demand Status --- 0% 100%
AV9
Eff_T Effective temperature used for control Status --- -40°F (-40°C) 122°F (50°C)
AV16
SATemp Supply air temperature Status --- -40°F (-40°C) 122°F (50°C)
AV19
SATFRSP_Set Set supply freezing temperature Status --- -40°F (-40°C) 122°F (50°C)
AV21
ECM_min_Set Fan analog min. output Cfg 0% 0% 100%
AV24
Fan_MinOn_Time Fan minimum ON time Cfg 10 min 0 min 60 min
AV27
OvrTime_Set Set occupancy override time Cfg 60 min 0 min 480 min
AV29
OATemp Outdoor air temperature Status --- -40°F (-40°C) 122°F (50°C)
AV31
CO2_SP_Set Set CO2 Setpoint Cfg 800 PPM 0 PPM 2000 PPM
AV33
MinCLSP Set minimum cooling setpoint Cfg 60°F (15°C) 54°F (12°C) 100°F (37.5°C)
AV34
MaxHTSP Set maximum heating setpoint Cfg 82°F (28°C) 40°F (4.5°C) 90°F (32°C)
AV35
OccCLSP Set occupied cooling setpoint User 73°F (23°C)
AV36
OccHTSP Set occupied heating setpoint User 71°F (21°C)
AV37
SP_DB_Set Set deadband Cfg 2°F (1°C) 2°F (1.1°C) 5°F (2.8°C)
AV38
Unoc_CL_Set Set unoccupied cooling setpoint Cfg 79°F (26°C)
AV39
Unoc_HT_Set Set unoccupied heating setpoint Cfg 65°F (18°C)
AV40
STBCoolOffset Set standby cooling offset (+) Cfg + 2°F (1.1°C) 2°F (1.1°C) 5°F (2.8°C)
AV41
STBHeatOffset Set standby heating offset (-) Cfg - 2°F (1.1°C) 2°F (1.1°C) 5°F (2.8°C)
AV42
EffCLSP Effective cooling setpoint Status ---
AV43
EffHTSP Effective heating setpoint Status ---
Please note that objects tagged as:
• Cfg: represent configuration properties of the device that are typically only set once during commissioning and start-up
• User: represent properties or objects that are typically manipulated by users of the controller
• Status: represent objects or properties that are ‘’typically’’ meant to be displayed on graphics for various required visualization
• Cmd: represent objects that can be controlled directly by other BACnet external process
