M7 OMPHOBBY - Install Transmission Components; Main Rotor Installation and Linkages

Hex Bolt (Half
Thread) M4x23 (×1)
(7-137)
M4 Nyloc Nut (×1)
(7-164)
01 Main Rotor Installation
02 Main Rotor Linkage Installation
Main Rotor
Linkage Rod
Install transmission components
Page
The ball joint sockets need to be installed
with the OMPHOBBY logo facing outwards.
BAG 27
