M7 OMPHOBBY - Transmission Installation; Swashplate Guide and Main Rotor Head

01 Swashplate Guide Installation
Hex Screw
M3x12 (×2)
(7-129)
Swashplate Guide (×1)
(7-039J)
02 Main Rotor Head Installation
Transmission Installation
Main Rotor Head Assembly
Page
The swashplate driver arm screws are tightened in this step to clamp the
main rotor yoke onto the main shaft. Tighten the screws evenly and in small steps
to ensure proper alignment!
Glue
BAG 26
