M7 OMPHOBBY - Belt Tensioning Procedure; Belt Tensioning Steps

Belt Tensioning Procedure
Page
Step 1 Step 2
Step 3 Step 4
Fully unscrew the belt
tensioner knob.
Pull the tail boom back until the belt has
no slack remaining, but no further.
Tighten the two boom
clamping screws on the
right side of the lower
frame.
Return the belt tensioner
system to its neutral position.
Confirm good tension of the belt!
Glue
