M7 OMPHOBBY - Installation of the Tensioner Screw; Tensioner Assembly

Hex Screw
M3x6 (×2)
(7-126)
Hex Screw
M2.5x6 (×3)
(7-122)
Tensioner Screw
Guidance Plate (×1)
(7-012)
Button Head Screw
M2.5x10 (×2)
(7-148)
Tensioner Knob (×1)
(7-047)
Tensioner
Threaded Pin (×1)
(7-046)
Tensioner Base (×1)
(7-014)
01 Tensioner Assembly
Installation of the Tensioner Screw
Page
Glue
Glue
Glue
BAG 7
