ESC and Flight Controller Installation
Page
These six screws can be removed when
installing the ESC for easier installation.
Hex Bolt
M2.5x10 (×4)
(7-230)
M2.5 Nylon Locknut (×4)
(7-162)
Flight Controller (×1)
(7-196)
02 Flight Controller Installation01 ESC Installation
ESC (×1)
(7-197)
BAG 30
