OPERATOR’S STATION
Form # 169304 34 Model Year - 2009
ENGINE RUNNING/HEADER ENGAGED
DRAPER HEADER/INDEX SWITCH ON
(Scroll Through Display with CDM Switch or GSL Switch)
DISPLAY (Lower or Upper Line)
DESCRIPTION
#####.# ENGINE HRS
Total Engine Operating Time.
#####.# HEADER HRS
Total Header Operating Time.
##.# ACRES/HOUR
##.# HECTARES/HOUR
(If Metric)
Actual Cutting Rate In Acres (Hectares)/Hour.
###.# SUB ACRES
###.# SUB HECTARES
(If Metric)
Area Cut Since Last Reset.
###### TOTAL ACRES
###### TOTAL HECT
(If Metric)
Total Area Cut By Machine.
##.## ##.# REEL IND
(Optional)
##.## REEL SENSOR (If Sensor Disabled)
Reel Peripheral Speed Along With Ground Speed In
MPH Or KPH.
##.# ##.# DRAP INDX
Draper Speed Along With Ground Speed In MPH Or
KPH.
#### KNIFE SPEED (Optional)
#### KNIFE SENSOR
(If Sensor Disabled)
Knife Speed In Strokes Per Minute.
##.# HEADER HEIGHT
##.# HEADER SENSOR
(If Sensor Disabled)
Distance Setting (00.0-10.0) Between Cutterbar &
Ground.
##.# HEADER ANGLE
(Optional)
##.# HEADER SENSOR
(If Sensor Disabled)
Angle Setting (00.0-10.0) Header Relative To
Ground.
FUEL LEVEL |■■■■|■■■■|
Level of Fuel In Tank.
ENGINE TEMP ### ° F
ENGINE TEMP ### °C
(If Metric)
Engine Coolant Temperature.
##.# VOLTS
Engine Electrical System Operating Voltage.
SCROLL
(Lower Line)
Displays Sub-Menu After 2-3 Seconds.
(Scroll Through Sub-Menu Display with CDM Switch)
SCROLL SUB-MENU (Lower Line Only)
#### KNIFE SPEED
(Optional)
##.# HEADER HEIGHT
##.## ##.# REEL INDRPM
##.# ##.# DRAP INDX
FUEL LEVEL |■■■■|■■■■|
ENGINE TEMP ### ° F
ENGINE TEMP ### °C
(If Metric)
##.## REEL MIN RPM
(Lower Line) (Optional)
Reel Speed Is Less Than Programmed Set-Point.
MINIMUM
(Lower Line) (Optional)
