MAINTENANCE WORK
DRIVE TRAIN
Maintenance manual T225/T230 69
Fig. 38: Oil dip stick
1 Oil filler nozzle
2 Oil dip stick
3 HOT CHECK range
4 COLD CHECK range
X
Check the oil level with the oil dip stick before you start the
motor for the first time.
Make sure the oil level is in the “HOT CHECK” range while
the oil is cold and the motor is at standstill.
X Refill oil into the oil filler nozzle if necessary.
If the oil level is correct, you can start with the cold check.
