11Magellan SporTrak GPS Receiver
Position Screens. The Position screens 1 and 2 display
your present position using the coordinate systems that you
have selected in Setup. This screen shows all of the basic
position, time and satellite information. In addition,
current navigation information is shown in the bottom half
of the screen.
Road Screen. The Road screen presents your route as if
you were travelling on a road. When you need to make a
turn, the road will graphically display the turn and the
direction. Waypoint and destination icons will be
displayed relative to your position as they come into view.
Above the road is a compass that displays your heading
and above that are four customizable data fields.
Satellite Status Screen. The Sat Status screen provides
you with a graphical display of the satellites in view and
which ones are being used to compute the navigation
data. The bar graph shows you the relative signal
strength being received for each satellite. At the bottom
of the display is an indication of the battery life
remaining. When you are using external power, it will be
indicated here as well.
From any screen other than a navigation screen, pressing [NAV]
returns you to the last navigation screen viewed. Note that if you are
inputting data, pressing [NAV] will return you to the last navigation
screen but your inputs will not be saved.
