Flex 8EX / 12EX EU System Instruction Manual
March 2018
Page 26 of 66
For 8EX:
NOTE: *PB8 is not available on the A/B transmitters
PB5…PB8 Pushbutton number
Normal Normal momentary contact
LED 1…LED 4 Transmitter toggled with designated LED Display
For 12EX:
NOTE: *PB12 is not available on the A/B transmitters
PB7…PB12 Pushbutton number
Normal Normal momentary contact
LED 1…LED 4 Transmitter toggled with designated LED Display
DIP PB5 PB6 PB7 PB8*
1 00000000 Normal Normal Normal Normal
2 00000101 Normal Normal Normal
LED 4
3 00000110 Normal Normal
LED 3 LED 4
4 00000111 Normal
LED 2 LED 3 LED 4
5 00001000
LED 1 LED 2 LED 3 LED 4
DIP PB7 PB8 PB9 PB10 PB11 PB12*
1 00000000 Normal Normal Normal Normal Normal Normal
2 00001001 Normal Normal Normal
LED 4 Normal Normal
3 00001010 Normal Normal
LED 3 LED 4 Normal Normal
4 00001011 Normal
LED 2 LED 3 LED 4 Normal Normal
5 00001100
LED 1 LED 2 LED 3 LED 4 Normal Normal
6 00001101 Normal Normal Normal Normal Normal
LED 4
7 00001110 Normal Normal Normal Normal
LED 3 LED 4
8 00001111 Normal Normal Normal
LED 2 LED 3 LED 4
9 00010000 Normal Normal
LED 1 LED 2 LED 3 LED 4
