Flex 8EX / 12EX EU System Instruction Manual
March 2018
Page 65 of 66
8 System Specifications
Frequency Range: 433 - 434 MHz
Frequency Deviation: 12.5 KHz
Number of Channels: 62 channels
Modulation:
Digital Frequency Modulation based on Manchester Code,
20-bit address, 32-bit CRC Parity Check and Hamming Code.
Encoder & Decoder: Microprocessor-controlled
Transmitting Range: >100 meters (300 feet)
Frequency Control: Synthesized PLL (Phase Lock Loop)
Receiver Type: Frequency Auto Scanning
Receiver Sensitivity: -116 dBm
Antenna Impedance: 50 ohms
Responding Time: 60 milliseconds (average)
Transmitting Power: 1.0 mW
Enclosure Type: NEMA-4X
Enclosure Rating: IP66
Output Contact Rating: 250V @ 8 Amps
Transmitter Operating Voltage: 3.0VDC
Receiver Power Consumption: 11.0 VA
Receiver Supply Voltage: Voltage Setting
Min - Max
24VAC (22 - 26VAC)
42VAC (38 - 46VAC)
48VAC (43 - 53VAC)
110VAC (104 - 126VAC)
220VAC (207 - 253VAC)
380VAC (351 - 429VAC)
410VAC (400 - 480VAC)
12/24VDC (9 - 36VDC)
Operating Temperature: -25°C - 75°C / -13°F - 167°F
Transmitter Dimension: 8EX: 184 mm (L) x 69 mm (W) x 34 mm (H)
12EX: 230 mm (L) x 69 mm (W) x 35 mm (H)
Receiver Dimension: 306 mm (L) x 228 mm (W) x 84.6 mm (H)
Transmitter Weight: 8EX: 242 g / 8.5 oz
12EX: 296 g / 10.4 oz
Receiver Weight: 2.5 kg / 5.5 lb
