Magnetek IMPULSE Link 5 - Professional Kit Contents; Wireless Diagnostic System (WDS) Option; Industrial Communication Options; System Requirements

IMPULSE
®
•Link 5 Instruction Manual
April 2020
Page 7 of 47
1.2. Professional Kit Contents
1.3. Wireless Diagnostic System (WDS) Option
An optional WDS hardware system is available to connect drives wirelessly, but not required. WDS
allows up to 31 drives to connect to a single Remote Unit. Multiple Remote Units can connect to a
single Base Unit.
1.4. Industrial Communication Options
IL5 Professional can connect with available IMPULSE Series 4 and G+ Mini Ethernet option cards.
1.5. System Requirements
• 1.5 GHz processor or better
• 2 GB RAM (minimum); 4 GB (recommended)
• Minimum of 300 MB free hard-disk space available
• Windows Vista, Windows 7, Windows 8, or Windows 10 operating system
• 32-bit or 64-bit
• Available USB port
IMPULSE Link 5 Professional Kit (IL5-PRO-KIT)
Part Number
IL5 Software Installer USB Flash Drive
IL5-SOFTWARE-USB
Unikey USB Software Licensing Key
IL5-PRO-KEY
Series 4/Series 3/G+ Mini: RJ45-to-Serial Adapter
CABLE-RJ45-DB9F
Series 4/Series 3/G+ Mini: Serial-to-USB Adapter (Keyspan)
ADAPTER-DB9M-USBA
DDC-S2 / DMC-S2: USB Cable
CABLE-USBA-USBMICROB
DDC-S1 / DMC-S1: DB9-to-Terminal Block Cable
CABLE-TB-DB9F
DSD: RJ12-toRJ12 PDCU Cable
CABLE-RJ12-RJ12
DSD: RJ12-to-DB9F Adapter
ADAPTER-RJ12-DB9F
Wireless Diagnostics System (WDS)
Part Number
Base Unit
WDS-BASE
Remote Unit (AC Input)
WDS-REMOTE-AC
Remote Unit (DC Input)
WDS-REMOTE-DC
Industrial Communication Option Cards
Part Number
EtherNet/IP
SI-EN3
EtherNet/IP (Dual-Port)
SI-EN3D
Modbus TCP/IP
SI-EM3
Modbus TCP/IP (Dual-Port)
SI-EM3D
PROFINET
SI-EP3
