16 Series, Model - 2816 4WD
Electrical System
Type of System ................................................... 12 Volt, Negative Ground
Battery ................................................................
EXIED 58-60 12V-540CCA
9-
13
/
16
L; 7-
13
/
16
W; 7H
SAE TAPER
Alternator ........................................................... 12Volt, 50 Ampere Output
Voltage Regulator........................................................IC Built in Alternator
Starter Motor ............................ 12 Volt, 1.6 kW with Solenoid Switch
Head Lamp .......................................................................................35 watt
Flasher Lamp .................................................................................. 32 watt
Rear Red Lamp................................................................................ 8 watt
Rear Working Lamp (If Equipped) ................................................. 23 watt
Panel Lamp .....................................................................................3.4 watt
Turn Indicator Lamp .......................................................................2.0 watt
Indicator Lamp............................................................................... 2.0 watt
Fuses
Glove indicator lamp..................................................................................10 Amp
Charge indicator lamp, Engine oil pressure indicator lamp................... 10 Amp
Engine Coolant Temperature Gauge, Fuel Gauge, Fuel Pump
Head lamps, Rear Red Lamp, High Beam indicator lamp .................... 15 Amp
Instrument Panel Lamps
Turn signal lamps ......................................................................................15 Amp
Other optional electrical equipments ........................................................15 Amp
SPECIFICATIONS
121
ELECTRICAL SYSTEM_________________________________________________
