16 Series, Model - 2816 4WD
Hydraulic System
Hydraulic Pump Type ..................... Front Mounted, Engine Driven, Pres-
sure Loading Gear Type
Capacity
Pump for Three Point Hitch .................................... 29.6
l /min. (7.8GPM)
at 2600 EngineRPM
Pump for Power Steering.......................................... 13.4
l
/mm.(3.5GPM)
at 2600 EngineRPM
Maximum System Pressure .......................................... 14710 kPa (2133 PSI)
Remote Hydraulic Control Valve (OPTIONAL) ........... One Double acting Type
............................................................................. Auxiliary Valve Available
Auxiliary Connector ................................................ ....... Front Hydraulic Block
Connector Size .............................................................. 9.5 mm (3/8inch)
Rear Power Takeoff (PTO)
PTO Type
Gear Drive ................................................................................. Live PTO
Location ................................................................ At the rear of transmission
Rotation ........................................................... Clockwise from rear of tractor
Shaft Size ...................................... 34.9mm(1.375 Inch) Diameter, 6 Splines
Speed............................................................ 540 RPM at 2376 Engine RPM
Mid Power Takeoff (PTO)(OPTIONAL)
PTO Type
Gear Drive .................................................................................. Live PTO
Location ..........................................................At the Bottom of Transmission
Rotation ........................................................ Clockwise from Rear of Tractor
Shaft Size ........................................ 25.4 mm (1 Inch) Diameter, 15 Splines
Speed.......................................................... 2000 RPM at 2632 Engine RPM
Drawbar
Type ................................................................................................Fixed Type
Distance from Hitch Hole to the END of PTO Shaft .... 85 mm (3.346 inch)
Maximum Vertical Load on Drawbar .................................... 136kg (300 lbs)
23
SPECIFICATIONS_______________________________________________________
